Dashboard Overview

Real-time monitoring of all distribution transformers

Total Transformers

3 Normal1 Warning1 Critical

Active Power

2065.5 kW

2145.8 kVA apparent

Technical Losses

2.73%

Normal range

Avg Transformer Age

2.8 years

Fleet average service life

Active Alarms

4 total alarms

Average Current per Phase

Real-time current distribution across phases

Average Voltage per Phase

Voltage levels across all transformers

Total Harmonic Distortion

Average THD across all transformers

3.42%

Average THDv

Average Body Temp

Temperature monitoring across fleet

74.6°C

Fleet average

Load Factor & Status

Current load factor and operational status of all transformers

ID	Name	Address	Status	Load Factor	Body Temp	THDv	Breaker
TRF-001	T1	Industrial Zone, Sheikh Zayed Street, Abu Dhabi, UAE	Normal	75%	65°C	2.1%	CONNECTED
TRF-002	T2	Al Manara District, Corniche Road, Abu Dhabi, UAE	Warning	92%	82°C	4.2%	CONNECTED
TRF-003	T3	Marina Mall Area, Zayed Street, Abu Dhabi, UAE	Normal	68%	60°C	1.8%	CONNECTED
TRF-004	T4	Al Mina District, Port Road, Abu Dhabi, UAE	Critical	98%	98°C	6.5%	CONNECTED
TRF-005	T5	Downtown Abu Dhabi, Bain Al Jessrain Street, Abu Dhabi, UAE	Normal	80%	68°C	2.5%	CONNECTED
